Bacterial Filter
5 0 ReviewsThe ZHENFU Bacterial / Viral Filters provide effective protection from microbial cross contamination. This range has been designed for use in breathing and anesthetic systems for the protection of the patient, hospital personnel and the equipment from potential microbial contamination. The ZHENFU Bacterial / Viral Filters are designed with standard ISO fittings to ensure a perfect connection to different ventilators and anesthesia systems. The high efficiency and the very low/stable breathing resistance are the strength of ZHENFU Bacterial / Viral Filters line.Connectors: Material: Size: Dead Speace: Quantity:
-
ZF-019
-
ZHENFU
REF
ZF-019
Version
Adult
Housing Material
ABS
Media
Pleated Glass Fiber Paper
BFE
99.99999%
VFE
99.9999%
Resistance @ 30L/min
255pa
Resistance @ 60L/min
539pa
Resistance @ 90L/min
1233pa
Tidal Volume Range
250ml-1500ml
Dead Space
35ml
Connector
22F/15M-22M/15F
Sampling Port
Yes
Weight
28.5g
Size
H:72mm;W:46mm;L:46mm
